Harnitek Commercial Packages
With outputs of up to 90kW, the Harnitek Commercial Package is the class-leading Harnitek Power XR. With strong outputs, combined with flow temperatures of up to 60°C, it can be cascaded up to 16 units, making it ideal for larger buildings and systems.
The Power XR range has been designed to make the transition from traditional energy sources to a renewable alternative.
With an in-built control system which allows for easy integration with other thermal technologies and existing building management systems.
Harnitek Commercial at a Glance
Key Harnitek Commercial Features
Outputs of up to 90kW
Flow temperatures of up to 60c
Cascade up to 16 units
BMS-ready control unit
Simple installation
Highly efficient A++ ERP rated
Built-in weather compensation
Cost-effective solution
Smart defrosting
Two mixing circuits
WiFi module
Modbus communication
Emergency operation switch
Product Outline
Harnitek Commercial Package Specifications
Minimum/Maximum Heating Capacity: 7.9-25.1kW
El. Heating Power Input Minimum/Maximum: 2564-6172W
C.O.P Minimum/Maximum: 3.07-4.41
Minimum/Maximum Heating Capacity (2): 9.9-24.8kW
El. Heating Power Input Minimum/Maximum (2): 3141-7625W
C.O.P Minimum/Maximum (2): 3.16-3.43
Minimum/Maximum Heating Capacity (3): 10.6-21.5kW
El. Heating Power Input Minimum/Maximum (3): 2528-7678W
E.E.R Minimum/Maximum (3): 2.81-4.2W
Minimum/Maximum Cooling Capacity (4): 7.1-18.1kW
El. Cooling Power Input Minimum/Maximum (4): 2570-6746W
Minimum/Maximum Ambient Working Temperature in Heating Mode: -25-45°C
Minimum/Maximum Ambient Working Temperature in Cooling Mode: 20-45°C
Maximum Flow Temperature in Heating Mode: 60°C
Minimum Flow Temperature in Heating Mode: 10°C
Minimum Flow Temperature in Cooling Mode: 5°C
Sound Power Level: 62dB
Fan Quantity: 2pcs
Fan Airflow: 5000*2
Fan Rated Power: 118*2
Fan Blade Diameter: 550*2
Minimum/Maximum Heating Capacity: 15.2-28.7kW
El. Heating Power Input Minimum/Maximum: 3467-7488W
C.O.P Minimum/Maximum: 3.83-4.43
Minimum/Maximum Heating Capacity (2): 12.2-29.4kW
El. Heating Power Input Minimum/Maximum (2): 3769-9035W
C.O.P Minimum/Maximum (2): 3.26-3.43
Minimum/Maximum Heating Capacity (3): 15.2-26.8kW
El. Heating Power Input Minimum/Maximum (3): 3253-8765W
E.E.R Minimum/Maximum (3): 3.06-4.68W
Minimum/Maximum Cooling Capacity (4): 7.3-21.2kW
El. Cooling Power Input Minimum/Maximum (4): 3121-7960W
Minimum/Maximum Ambient Working Temperature in Heating Mode: -25-45°C
Minimum/Maximum Ambient Working Temperature in Cooling Mode: 20-45°C
Maximum Flow Temperature in Heating Mode: 60°C
Minimum Flow Temperature in Heating Mode: 10°C
Minimum Flow Temperature in Cooling Mode: 5°C
Sound Power Level: 62dB
Fan Quantity: 2pcs
Fan Airflow: 5250*2m3/h
Fan Rated Power: 93*2W
Fan Blade Diameter: 552*2mm
Minimum/Maximum Heating Capacity: 13.7-43.7kW
El. Heating Power Input Minimum/Maximum: 3325-12077W
C.O.P Minimum/Maximum: 3.62-4.42
Minimum/Maximum Heating Capacity (2): 13.6-43.2kW
El. Heating Power Input Minimum/Maximum (2): 4156-14308W
C.O.P Minimum/Maximum (2): 2.99-3.38W
Minimum/Maximum Heating Capacity (3): 17.7-32.0kW
El. Heating Power Input Minimum/Maximum (3): 3491-11771W
E.E.R Minimum/Maximum (3): 2.72-5.09W
Minimum/Maximum Cooling Capacity (4): 11.2-29.9kW
El. Cooling Power Input Minimum/Maximum (4): 3529-11640W
Minimum/Maximum Ambient Working Temperature in Heating Mode: -25-45°C
Minimum/Maximum Ambient Working Temperature in Cooling Mode: 20-45°C
Maximum Flow Temperature in Heating Mode: 55°C
Minimum Flow Temperature in Heating Mode: 10°C
Minimum Flow Temperature in Cooling Mode: 5°C
Sound Power Level: 66dB
Fan Quantity: 1pcs
Fan Airflow: 13500m3/h
Fan Rated Power: 800W
Fan Blade Diameter: 760mm
Harnitek Commercial in depth
Harnitek Commercial Package Overview
Hybrid Compatibility
The control panel is able to control up to 16 units as part of the Cascade system. This means that complex networks can be built out of the main unit, which can be easily controlled and maintained by the Harnitek Power XR Controller.
WiFi Module
With in-built Wi-Fi Module, the Power XR range can be remotely controlled and monitored. As soon as a service is required, the connectivity will allow diagnoses for quick and easy fixes.
Run In Rotation
No matter how many different individual units are connected to the system, every single unit can run alternately.
Having this feature means that you can efficiently service separate areas with heating as and when required.
Data Monitoring
In-built Performance Hub Gateway gives a real time view of system operation and performance anywhere in the world.
Additionally, the data is logged on an online monitoring platform, keeping an accurate record of performance and energy consumption throughout the year.
Exceptionally Efficient
The Power XR range has a highly efficient A++ ERP rating.
This makes the units a cost-effective solution, especially with the larger scale systems, ensuring that every bit of energy counts.
