Harnitek Heatboost Radiator 3.1kW

SKU: HFP-350LM-Z1 Categories: , Tag:

Product Code: HFP-350LM-Z1

X
  • UK-based technical support team, always ready to assist
  • 5-Year Warranty

Harnitek Heatboost Radiator 3.1kW

SKU: HFP-350LM-Z1 Categories: , Tag:

Product Code: HFP-350LM-Z1

Introduction

Our Heatboost radiators are suitable for a wide range of product applications in both residential and commercial settings. They are especially suited for use with heat pumps due to their super low temperature operation, with an internal waterflow temperature starting at only 35°C. This makes them an ideal heating system of choice for new builds and anyone looking for a cost-saving and eco-friendly replacement for traditional heating.

Heatboost radiators can heat your home up to 7x more efficiently than a traditional steel convection radiator. One large Heatboost unit can replace two steel radiators in the same space with the same levels of heat efficiency without sacrificing comfort.

Key Features

  • Stylish Design
  • Compact Construction (130mm thick)
  • Quiet Operation & High Efficiency with DC motor
  • Touch Operation Panel
  • High output

Harnitek Heatboost Radiator 3.1kW

SKU: HFP-350LM-Z1 Categories: , Tag:
Cooling Performance

  • (a) Total Cooling Capacity (KW): 1.50
  • Sensible Cooling Capacity (KW): 1.25
  • Water Flow Rate (L/h): 302
  • Water Pressure Drops (kPa): 9.00
Dimensions and Weight

  • Net Dimensions (LxWxH) (mm): 894 x 134 x 588
  • Package Dimensions (LxWxH) (mm): 920 x 165 x 630
  • Net Weight (Kg): 17
  • Gross Weight (Kg): 18.5
Heating Performance

  • (b) Heating Capacity (KW): 2.00
  • Water Flow Rate (L/h): 302
  • Water Pressure Drops (kPa): 7.00
  • (c) Heating Capacity (KW): 3.10
  • Water Flow Rate (L/h): 343
  • Water Pressure Drops (kPa): 7.50
Components

  • Coil Water Content (L): 0.85
  • Maximum Operating Pressure (bar): 10
  • Water Pipe Connector (inches): G1/2
  • (d) Maximum Air Flow (m³/h): 320
  • (d) Minimum Air Flow (m³/h): 150
Power Supply

  • Power Supply (V/ph/Hz): 230/1/50
  • Maximum Running Current (A): 0.12
  • Maximum Power Input (W): 28
  • (e) Maximum Noise Level (dB(A)): 40
  • (e) Minimum Noise Level (dB(A)): 18.3
Note:

  1. Cooling: Water inlet/outlet 7/12°C, room temperature DB/WB 27/19°C
  2. Heating: Water inlet 50°C, water flow rate as in cooling operation, room temperature 20°C
  3. Heating: Water inlet 70°C, outlet 60°C, room temperature 20°C
  4. Air flow measured with clean filter
  5. Noise tested as per ISO23741/2 and ISO7779:2001

The specifications are subject to change without prior notice. For actual specifications of unit, please refer to the stickers on the unit.
